MQA5322-DVK
€180.00
Availability
Deliverable in short time
More information about samples availability can be found here: Availability
Development Kit for the following SOMs
MQA5312-C0-1U
MQA5321-C0-2U
MQA5322-C0-3U
MQA5312-C0-1U
MQA5321-C0-2U
MQA5322-C0-3U
Product Code:
336707
Weight: 0 g
Manufacturer: METICOMM
Weight: 0 g
Manufacturer: METICOMM
Detailed information
- Based on MQA5322-C0-2U
- 1 x M.2 Key-E slot with PCIe&USB&UART&PCM Interface for Wi-Fi/BT Module support
- 1 x M.2 Key-B slot with USB 2.0 & Uart interface for cellular module support
- 1 x SIM card
- 1 x PMOD socket with UART&I2C
- 1 x PMOD socket with SPI&I2C
- 2 x RS485 connector
- 1 x USB2.0 Type A connector
- 1 x USB2.0 Type C connector
- 1 x 2.5Gigabit Ethernet LAN/WAN RJ45 Port
- 3 x Gigabit Ethernet LAN RJ45 Port
- 1 x SFP+ socket
- 1 x 12V DC Jack
- 1 x M.2 Key-E slot with PCIe&USB&UART&PCM Interface for Wi-Fi/BT Module support
- 1 x M.2 Key-B slot with USB 2.0 & Uart interface for cellular module support
- 1 x SIM card
- 1 x PMOD socket with UART&I2C
- 1 x PMOD socket with SPI&I2C
- 2 x RS485 connector
- 1 x USB2.0 Type A connector
- 1 x USB2.0 Type C connector
- 1 x 2.5Gigabit Ethernet LAN/WAN RJ45 Port
- 3 x Gigabit Ethernet LAN RJ45 Port
- 1 x SFP+ socket
- 1 x 12V DC Jack
