Electrolytic Capacitors
With Long Guaranteed Lifetime
With high quality manufacturers CODICO is focusing on applications with high requirements for the (electrolytic capacitors) e-caps. In many cases a special, fitted to the application capacitor will be designed, in order to provide a technically and commercially optimal solution.
CODICO's manufacturers put strong focus on developing high performance e-caps – long guaranteed lifetime, high ripple current capability, low ESR and miniaturization are the priorities. In addition e-caps with a wide temperature range are part of the portfolio.
Samples Contacts NewsManufacturers & Contacts
AISHI
AISHI is a brand of the Aihua Group, a Chinese manufacturer focused on the design, development and manufacturing of aluminum electrolytic capacitors. In addition the product portfolio includes polymer and film capacitors. AISHI's target markets include white goods, LED/lighting, industrial and new energy.
Infos SamplesPANASONIC
PANASONIC is a big Japanese manufacturer with different business areas like automotive with multi-media products, Manufacturing with electronic components mounting systems or industrial robots and finally the Industrial Business Group with electronic components. CODICO's main focus is on polymer and hybrid capacitors, metal alloy inductors and precision and measurement resistors.
Infos SamplesRUBYCON
RUBYCON is one of the worldwide leading Japanese manufacturers of aluminium electrolytic capacitors. The company is market leader in long life e-caps and very strong in high performance e-caps with high ripple current/low impedance and continuous miniaturization.
Infos SamplesSUNCON
SUN is a Japanese manufacturer of high-quality aluminum electrolytic and hybrid capacitors with more than 60 years of experience in development and production. In 2000, the company introduced the world's first polymer hybrid electrolytic capacitor to the market, which offers major advantages over conventional electrolytic capacitors.
Infos Samples-
Electrolytic Capacitors 35TKV100M8x10.5Rated Voltage: 35Vdc
Capacitance: 100µF
Rated Ripple Current @100kHz: 850mA rms
Impedance/ESR: 0,08Ω
Free Sample
-
Electrolytic Capacitors 35TKV150M8x10.5Rated Voltage: 35Vdc
Capacitance: 150µF
Rated Ripple Current @100kHz: 850mA rms
Impedance/ESR: 0,08Ω
Free Sample
-
Electrolytic Capacitors 35TKV220M8x10.5Rated Voltage: 35Vdc
Capacitance: 220µF
Rated Ripple Current @100kHz: 850mA rms
Impedance/ESR: 0,08Ω
Free Sample
-
Electrolytic Capacitors 6.3TKV470M8x10.5Rated Voltage: 6,3Vdc
Capacitance: 470µF
Rated Ripple Current @100kHz: 850mA rms
Impedance/ESR: 0,08Ω
Free Sample
-
Electrolytic Capacitors 10TPV1000M8x10.5Rated Voltage: 10Vdc
Capacitance: 1000µF
Rated Ripple Current @100kHz: 850mA rms
Impedance/ESR: 0,08Ω
Free Sample
-
Electrolytic Capacitors 25TPV470M8x10.5Rated Voltage: 25Vdc
Capacitance: 470µF
Rated Ripple Current @100kHz: 850mA rms
Impedance/ESR: 0,08Ω
Free Sample
-
Electrolytic Capacitors 35TPV330M8x10.5Rated Voltage: 35Vdc
Capacitance: 330µF
Rated Ripple Current @100kHz: 850mA rms
Impedance/ESR: 0,08Ω
Free Sample
-
Electrolytic Capacitors 6.3TPV1200M8x10.5Rated Voltage: 6,3Vdc
Capacitance: 1200µF
Rated Ripple Current @100kHz: 850mA rms
Impedance/ESR: 0,08Ω
Free Sample
-
Electrolytic Capacitors 10TRV330M8x10.5Rated Voltage: 10Vdc
Capacitance: 330µF
Rated Ripple Current @100kHz: 600mA rms
Impedance/ESR: 0,15Ω
Free Sample
-
Electrolytic Capacitors 16TRV330M8x10.5Rated Voltage: 16Vdc
Capacitance: 330µF
Rated Ripple Current @100kHz: 600mA rms
Impedance/ESR: 0,15Ω
Free Sample
-
Electrolytic Capacitors 35TRV100M8x10.5Rated Voltage: 35Vdc
Capacitance: 100µF
Rated Ripple Current @100kHz: 600mA rms
Impedance/ESR: 0,15Ω
Free Sample
-
Electrolytic Capacitors 50TRV47M8x10.5Rated Voltage: 50Vdc
Capacitance: 47µF
Rated Ripple Current @100kHz: 350mA rms
Impedance/ESR: 0,36Ω
Free Sample
